Huawei FusionServer XH321 V3 Server Node

The Huawei FusionServer XH321 V3 is a cutting-edge, half-width 2-socket compute node tailored for the Huawei X6800 high-density server system. It leverages the power of Intel® Xeon® E5-2600 v3/v4 processors and supports 16 DDR4 DIMM slots, delivering high performance for resource-intensive applications such as cloud computing and HPC. One of its standout features is the ability to house up to 6 NVMe SSDs, providing an incredible 4.8 million IOPS to significantly boost storage performance. With its modular design, smart power management, and advanced remote administration via Huawei eSight, the XH321 V3 offers extreme efficiency for space-constrained data centers.

Technical Specifications:

• Form Factor: 1U half-width server node.

• Processors: Up to 2 x Intel® Xeon® E5-2600 v3/v4 series.

• Memory: 16 DDR4 DIMM modules.

• Storage: 6 x 2.5-inch SAS/SATA HDDs or NVMe/SAS/SATA SSDs.

• Networking: LOM ports supporting 2 GE or 2 GE + 2 x 10 GE.

• Expansion: 2 PCIe expansion slots available.

• Management: IPMI 2.0, SNMP, Virtual KVM, and Huawei eSight management software.

• OS Support: Windows Server, RHEL, SLES, CentOS, VMware, and Citrix.
