Optical pigtail SC
The SC Optical Pigtail (Singlemode) is a professional-grade fiber management component designed for terminating fiber cables via fusion or mechanical splicing. It features a 1.5-meter 0.9mm buffered fiber pre-terminated at one end with a high-quality SC connector.
The SC series offers two polishing options: SC/UPC for standard singlemode applications and SC/APC for applications requiring high return loss, such as GPON and CATV. Its 0.9mm outer diameter provides the necessary flexibility for tight routing inside distribution frames and subscriber outlets while ensuring low insertion loss and reliable performance.
Key Specifications:
-
Connector Type: SC/UPC or SC/APC Simplex.
-
Fiber Diameter: 0.9 mm.
-
Length: 1.5 m.
-
Application: Splicing in patch panels, distribution boxes, and FTTH outlets.
-
Operating Temp: -10°C to +60°C.
